7409 BGM SKF Single Row Angular Contact Ball Bearing 45mm x 120mm x 29mm
7409 BGM SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from SKF is engineered to handle combined radial and axial loads simultaneously, making it ideal for high-speed precision applications. The robust 45mm bore design provides excellent load capacity and reliability for demanding industrial environments.
Key Features:
- Single row configuration for precision radial and axial load handling
- Brass cage construction for optimized performance and durability
- 40-degree contact angle for enhanced load distribution
- Open bearing design without seals, suitable for pre-lubricated applications
- Normal radial clearance for standard operating conditions
- Standard bearing steel construction with P0/PN2 tolerance class (ABEC 1)
- Wide temperature operating range: -20°C to +150°C
- Compact dimensions: 45mm bore x 120mm OD x 29mm width
Specifications:
- Reference: 7409BGM
- Brand: SKF
- Inside Diameter: 45mm
- Outside Diameter: 120mm
- Width: 29mm
- Row Type: Single
- Cage Material: Brass
- Contact Angle: 40 degrees
- Seal Type: Open bearing (None)
- Clearance: Normal radial clearance
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +150°C
- Outer Ring: Without flange/groove
Applications:
This SKF angular contact bearing is ideal for industrial machinery, gearboxes, motor spindles, compressors, and other equipment requiring reliable performance under combined radial and axial loads. The open design makes it particularly suitable for applications where external lubrication systems are employed. Its versatile size makes it perfect for medium-duty industrial equipment and precision machinery requiring robust performance.
