7334-B-MP-UO FAG Single Row Angular Contact Ball Bearing 170mm x 360mm x 72mm
7334-B-MP-UO FAG Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from FAG is engineered for demanding high-speed, high-precision applications requiring simultaneous radial and axial load handling. With its robust 170mm bore and 360mm outer diameter, this bearing delivers exceptional load capacity and reliability in heavy-duty industrial environments. The open design and specialized brass cage construction make it ideal for applications requiring high-speed operation and minimal maintenance.
Key Specifications:
- Bore Diameter: 170mm
- Outer Diameter: 360mm
- Width: 72mm
- Row Type: Single Row
- Contact Angle: 40 degrees
- Seal Type: Open bearing (none)
- Cage Material: Brass
- Clearance: Normal radial clearance
- Arrangement: Clearance-free in O- and X-arrangement (bearing pair)
- Tolerance Class: P0/PN2 (ABEC 1)
- Material: Standard bearing steel
- Temperature Range: -20°C to +200°C
- Outer Ring: Without flange or groove
- Manufacturer: FAG
- Reference: 7334-B-MP-UO
Technical Features:
- 40-degree contact angle optimizes load distribution for combined radial and axial load handling
- Brass cage construction provides superior performance in high-speed applications and extended operational life
- Open bearing design allows for external lubrication systems and custom maintenance protocols
- Clearance-free arrangement in both O- and X-configurations enables flexible mounting for bearing pairs
- Large bore diameter (170mm) accommodates substantial loads typical in industrial machinery
- Extended temperature range (-20°C to +200°C) provides reliable operation in demanding thermal environments
- Standard bearing steel material ensures durability and consistent long-term performance
- Outer ring without flange provides flexible mounting options for diverse applications
- High precision P0/PN2 tolerance class guarantees smooth, vibration-free operation
Applications:
Ideal for gearboxes, heavy-duty machine tools, large electric motors, industrial pumps, compressors, spindle bearings, and other precision applications where high-speed operation, combined loading, extended temperature stability, and heavy load capacity are essential requirements.
