7332-B-MP-UO FAG Single Row Angular Contact Ball Bearing 160mm x 340mm x 68mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair is clearance-free in O- and X-arrangement
Brand
FAG
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
160mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
340mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +200 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
68mm
Reference
7332-B-MP-UO
Additional Reference:
10076401
Quick Order Code
BB-504293
Product Description
7332-B-MP-UO FAG Single Row Angular Contact Ball Bearing
This premium angular contact ball bearing from FAG is engineered to deliver exceptional performance in high-speed, precision applications requiring simultaneous radial and axial load capacity. The 7332-B-MP-UO is an industrial-grade bearing designed for demanding heavy-duty equipment and machinery where reliability and durability are essential.
Bearing Specifications:
- Bore Diameter: 160mm
- Outside Diameter: 340mm
- Width: 68mm
- Type: Single Row Angular Contact Ball Bearing
- Contact Angle: 40°
- Manufacturer: FAG
- Reference Number: 7332-B-MP-UO
Key Features:
- 40° contact angle for optimised load distribution and enhanced performance
- Standard bearing steel construction for superior durability
- Brass cage design for reliable ball spacing and reduced friction
- Normal radial clearance for standard applications
- Open bearing design with no seals for maintenance-free operation in clean environments
- Clearance-free bearing pair configuration in O- and X-arrangement for paired mounting flexibility
- Tolerance class P0/PN2 (ABEC 1) for precision performance
- Wide operating temperature range: -20°C to +200°C
- Accommodates axial loads in one direction with exceptional reliability
Why Choose FAG?
FAG is a globally recognised manufacturer of precision bearings with a reputation for engineering excellence and consistent quality. FAG bearings are trusted by leading industries for their superior performance in the most demanding applications.
Typical Applications:
- Large industrial gearboxes and transmissions
- Heavy-duty machinery and equipment
- Machine tool spindles and precision machinery
- Pump and compressor systems
- Power generation equipment
- Railway and automotive transmission systems
- Industrial applications requiring large bore diameters and high load capacity
