Quick Code: BB-495651
7324-BCBM SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair with a low axial clearance in O- and X-arrangem
Brand
SKF
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
120mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
260mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +200 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
55mm
Reference
7324-BCBM
Additional Reference:
10017643
Quick Order Code
BB-495651
Product Description
7324-BCBM SKF Single Row Angular Contact Ball Bearing
Premium angular contact ball bearing from SKF, engineered for high-speed precision applications requiring simultaneous radial and axial load capacity. The 7324-BCBM is ideal for demanding industrial equipment including gearboxes, machine tool spindles, pumps, and heavy-duty rotating machinery.
Technical Specifications:
- Bore Diameter: 120mm
- Outer Diameter: 260mm
- Width: 55mm
- Contact Angle: 40°
- Row Type: Single row
- Arrangement: Bearing pair with low axial clearance in O- and X-arrangement
Material & Construction:
- Material: Standard bearing steel
- Cage: Brass cage for superior durability and stability
- Seal: Open bearing (none)
- Outer Ring: Without flange/groove
Performance Characteristics:
- Radial Clearance: Normal
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +200°C
SKF's proven engineering ensures reliable performance and extended service life in demanding applications. This bearing pair configuration with low axial clearance is particularly suited for precision gearboxes and other heavy-duty equipment requiring coordinated load distribution.
