7319-B-MP-UO FAG Single Row Angular Contact Ball Bearing 95mm x 200mm x 45mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair is clearance-free in O- and X-arrangement
Brand
FAG
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
95mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
200mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
45mm
Reference
7319-B-MP-UO
Additional Reference:
10017607
Quick Order Code
BB-495635
Product Description
The 7319-B-MP-UO FAG Single Row Angular Contact Ball Bearing is a precision bearing designed for high-speed applications requiring simultaneous radial and axial load capacity. This premium FAG bearing combines robust engineering with reliable performance for demanding industrial environments.
Key Specifications:
- Bore Diameter: 95mm
- Outer Diameter: 200mm
- Width: 45mm
- Brand: FAG
- Row Type: Single Row
- Contact Angle: 40°
Technical Features:
- Brass cage construction for enhanced durability and performance
- Normal radial clearance with clearance-free arrangement in O- and X-configurations
- Standard bearing steel material for reliability and longevity
- Open bearing design (no seal) for applications where lubrication management is handled externally
- Tolerance Class P0/PN2 (ABEC 1) for consistent precision
- Operating temperature range: -20°C to +150°C
- Without flange or groove outer ring for flexible mounting options
Ideal Applications:
This bearing is well-suited for gearboxes, spindles, electric motors, and other heavy-duty equipment where combined radial and axial loads are present. The 40° contact angle provides excellent load distribution and is particularly effective in precision machinery and industrial drive systems.
In stock for immediate dispatch. Contact us for custom configurations or alternative sizes.
