7310-BEGA-TVP NKE Single Row Angular Contact Ball Bearing 50mm x 110mm x 27mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Standard version
Brand
NKE
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
50mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
110mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
27mm
Reference
7310-BEGA-TVP
Additional Reference:
10172511
Quick Order Code
BB-529637
Product Description
The 7310-BEGA-TVP NKE Single Row Angular Contact Ball Bearing is a precision bearing engineered to handle combined radial and axial loads with reliable performance. As a product from NKE, a respected manufacturer of quality bearings, this single row design delivers consistent operation for a wide range of industrial applications.
Key Specifications:
- Bore Diameter: 50mm
- Outer Diameter: 110mm
- Width: 27mm
- Contact Angle: 40°
- Type: Single Row Angular Contact Ball Bearing
- Cage: Polyamide cage
- Clearance: Normal radial clearance
- Seals: Open bearing (unsealed)
- Tolerance Class: P0/PN2 (ABEC 1)
- Material: Standard bearing steel
- Arrangement: Standard version
- Outer Ring: Without flange or groove
Features & Benefits:
- Single Row Configuration – Compact design optimized for simultaneous radial and axial load capacity, ideal for space-constrained applications
- Open Design – Unsealed bearing allows for easy maintenance, inspection, and flexible mounting options
- Polyamide Cage – Lightweight, durable cage material for smooth operation and extended bearing life
- 40° Contact Angle – Higher contact angle provides enhanced axial load capacity while maintaining good radial performance
- Normal Clearance – Standard radial clearance suitable for general industrial applications
- Wide Temperature Range – Operating range from -20°C to +120°C for versatile deployment across varying environments
- Precision Quality – NKE's quality standards ensure consistent performance and reliability
Applications:
Ideal for gearboxes, electric motors, pumps, compressors, machine tool spindles, and other industrial machinery requiring efficient handling of combined loads. The open design makes it particularly suitable for applications where maintenance accessibility and ease of installation are important, or where external sealing solutions are preferred.
Reference: 7310-BEGA-TVP
