7222-BECBM SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Bearing pair with a low axial clearance in O- and X-arrangem
Brand
SKF
Cage
Brass cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
110mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
200mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +150 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
38mm
Reference
7222-BECBM
Additional Reference:
10059007
Quick Order Code
BB-500316
Product Description
7222-BECBM SKF Single Row Angular Contact Ball Bearing
Premium single row angular contact ball bearing from SKF, engineered for high-speed precision applications requiring simultaneous radial and axial load handling. This bearing is ideal for gearboxes, spindles, machine tool applications, pumps, electric motors, and other demanding industrial equipment.
Specifications:
- Bore Diameter: 110mm
- Outer Diameter: 200mm
- Width: 38mm
- Row Type: Single
- Contact Angle: 40°
- Arrangement: Bearing pair with low axial clearance in O- and X-arrangements
Key Features:
- Material: Standard bearing steel for superior durability and exceptional load capacity
- Cage: Brass cage for reliable performance and excellent stability at high speeds
- Clearance: Normal radial clearance
- Tolerance Class: P0/PN2 / ABEC 1 for reliable precision performance
- Seal Type: Open bearing (unsealed)
- Temperature Range: -20°C to +150°C
- Outer Ring: Without flange or groove
Perfect for applications requiring high-speed rotation with precision and reliability. The 40° contact angle provides excellent support for combined loads in both radial and axial directions. The brass cage construction ensures superior performance in demanding industrial environments.
