7221-BECBP SKF Single Row Angular Contact Ball Bearing
7221-BECBP SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact ball bearing from SKF is engineered for high-speed precision applications requiring simultaneous radial and axial load capacity. The 7221-BECBP is supplied as a bearing pair with low axial clearance, available in both O-arrangement and X-arrangement configurations, making it ideal for applications demanding precise load distribution and minimal play.
Key Features:
- Single row angular contact design with 40° contact angle for optimal load handling
- Bearing pair with low axial clearance in O- and X-arrangement options
- Polyamide cage for lightweight, durable operation
- Open bearing design (unsealed) for applications with effective external protection
- Normal radial clearance for standard applications
- Compact dimensions: 105mm bore x 190mm OD x 36mm width
- Trusted SKF manufacturing quality and precision
Specifications:
- Reference: 7221-BECBP
- Brand: SKF
- Bore Diameter: 105mm
- Outer Diameter: 190mm
- Width: 36mm
- Row Type: Single Row
- Contact Angle: 40°
- Arrangement: O-arrangement and X-arrangement pair
- Cage Material: Polyamide
- Seal Type: Open bearing (unsealed)
- Radial Clearance: Normal
- Tolerance Class: P0/PN2 (ABEC 1)
- Material: Standard bearing steel
- Temperature Range: -20°C to +120°C
Typical Applications:
These angular contact bearing pairs are ideal for use in industrial gearboxes, machine tool spindles, automotive transmissions, electric motors, and other precision equipment where controlled axial clearance and reliable combined load handling are essential.
