7220-BEP SKF Single Row Angular Contact Ball Bearing
7220-BEP SKF Single Row Angular Contact Ball Bearing
This premium SKF angular contact ball bearing is engineered to handle combined radial and axial loads simultaneously, making it ideal for high-speed, precision applications. As a single row design, it accommodates axial loads in one direction and features a non-separable construction for reliable performance in demanding industrial environments.
Key Features:
- 40° contact angle for optimal load distribution
- Optimised internal design for enhanced performance and durability
- Universal mounting configuration – two bearings can be arranged back-to-back or face-to-face with normal axial internal clearance before mounting
- Injection moulded polyamide cage with ball centring for reduced friction and improved reliability
- Open bearing design with no seals for applications where seal-free operation is preferred
- Manufactured by SKF – the world's largest bearing manufacturer, renowned for exceptional quality standards
Specifications:
- Bore Diameter: 100mm
- Outer Diameter: 180mm
- Width: 34mm
- Bearing Type: Single Row Angular Contact Ball Bearing
- Contact Angle: 40°
- Radial Clearance: Normal
- Cage Material: Polyamide
- Outer Ring: Without flange/groove
- Seal Type: Open bearing (None)
- Tolerance Class: P0/PN2 (ABEC 1)
- Temperature Range: -20°C to +120°C
- Material: Standard bearing steel
- Arrangement: Standard version
Applications:
Ideal for high-speed precision applications including gearboxes, electric motors, machine tools, pumps, and other heavy-duty industrial equipment where simultaneous radial and axial load capacity is essential. The open design makes it particularly suitable for applications in clean, controlled environments or where regular maintenance and cleaning are performed.
