7214-BEP SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Split Plummer Blocks - Housing Only
Buy Now
Product Specification
Arrangement
Standard version
Brand
SKF
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
70mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
125mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
24mm
Reference
7214-BEP
Additional Reference:
10028562
Quick Order Code
BB-496699
Product Description
7214-BEP SKF Single Row Angular Contact Ball Bearing
This premium single row angular contact bearing from SKF is engineered for high-speed, precision applications requiring simultaneous radial and axial load capacity. The 7214-BEP delivers reliable performance in demanding industrial environments with its robust construction and optimized design.
Specifications:
- Reference: 7214-BEP
- Manufacturer: SKF
- Bore Diameter: 70mm
- Outer Diameter: 125mm
- Width: 24mm
- Row Type: Single Row
- Contact Angle: 40 degrees
- Arrangement: Standard version
Key Features:
- Single row design for balanced radial and axial load handling
- 40-degree contact angle optimized for combined loading conditions
- Polyamide cage construction for lightweight performance
- Normal radial clearance (standard tolerance class P0/PN2 / ABEC 1)
- Open bearing design (no seals) for applications where minimal drag is required
- Standard bearing steel construction from leading manufacturer SKF
- Operating temperature range: -20°C to +120°C
Applications:
This bearing is ideal for use in gearboxes, machine tool spindles, automotive transmissions, industrial pumps, and other heavy-duty equipment where reliable performance under combined radial and axial loads is essential. Its standard configuration makes it suitable for general industrial machinery and precision rotating equipment.
