7210-BEP SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Standard version
Brand
SKF
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
50mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
90mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
20mm
Reference
7210-BEP
Additional Reference:
10017202
Quick Order Code
BB-495509
Product Description
The 7210-BEP SKF Single Row Angular Contact Ball Bearing is a versatile, precision-engineered bearing designed for demanding industrial applications requiring simultaneous radial and axial load handling at moderate to high speeds.
Specifications
- Brand: SKF
- Bore Diameter: 50mm
- Outer Diameter: 90mm
- Width: 20mm
- Row Type: Single row
- Contact Angle: 40°
- Radial Clearance: Normal
- Cage Material: Polyamide
- Bearing Steel: Standard bearing steel
- Seal Type: Open bearing (none)
- Outer Ring: Without flange or groove
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +120°C
Applications
This bearing is ideal for use in:
- Electric motors and generators
- Gearboxes and reduction units
- Machine tool spindles
- Automotive and industrial equipment
- Pumps and compressors
- General industrial machinery requiring precision and reliability
The standard arrangement, normal radial clearance, and robust polyamide cage make this bearing suitable for general-purpose industrial use where dependable performance and cost-effectiveness are essential.
