Quick Code: BB-495506
7209-BEP SKF Single Row Angular Contact Ball Bearing
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Standard version
Brand
SKF
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
40 degree
Inside Dia
45mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
85mm
Row Type
Single
Seal
None, open bearing
Temperature range
-20 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
19mm
Reference
7209-BEP
Additional Reference:
10017189
Quick Order Code
BB-495506
Product Description
7209-BEP SKF Single Row Angular Contact Ball Bearing
This premium SKF angular contact ball bearing is engineered to handle simultaneous radial and axial loads, making it ideal for high-speed precision applications. The 7209-BEP is a single row design capable of accommodating axial loads in one direction, featuring a robust open bearing construction for reliable performance in demanding environments.
Key Features:
- 40° contact angle for optimal load distribution and performance
- Polyamide cage for smooth, efficient operation
- Standard arrangement with normal radial clearance for versatile mounting options
- Open bearing design (no seals) for applications requiring minimal friction and heat generation
- Manufactured by SKF, the world's largest bearing manufacturer, renowned for exceptional quality standards
- Standard bearing steel construction for durability and reliability
Specifications:
- Bore Diameter: 45mm
- Outer Diameter: 85mm
- Width: 19mm
- Row Type: Single Row
- Cage Type: Polyamide
- Contact Angle: 40°
- Clearance: Normal radial clearance
- Seal Type: None (open bearing)
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -20°C to +120°C
- Reference: 7209-BEP
Applications:
Ideal for electric motors, gearboxes, machine tool spindles, pumps, compressors, and other industrial equipment requiring combined radial and axial load capacity at moderate to high speeds. Suitable for applications where minimal friction and heat generation are critical.
