7206-B-XL-TVP-P5-UA FAG Single Row Angular Contact Ball Bearing 30mm x 62mm x 16mm
7206-B-XL-TVP-P5-UA FAG Single Row Angular Contact Ball Bearing
This precision-engineered FAG single row angular contact ball bearing is designed for high-speed applications requiring simultaneous radial and axial loads. With dimensions of 30mm bore × 62mm outside diameter × 16mm width, this bearing delivers exceptional performance in demanding industrial and precision engineering applications. The P5 tolerance class ensures superior accuracy and smooth operation, making it ideal for applications where precision and reliability are paramount.
Key Specifications:
- Brand: FAG
- Bore Diameter: 30mm
- Outside Diameter: 62mm
- Width: 16mm
- Row Type: Single Row
- Contact Angle: 40°
- Seal Type: Open
- Cage Material: Polyamide
- Radial Clearance: Normal
- Tolerance Class: P5 / ABEC 5
- Material: Standard bearing steel
- Outer Ring: Without flange or groove
- Temperature Range: -20°C to +120°C
Design & Performance Features:
- Single Row Configuration: Optimized for unidirectional axial loads, making it ideal for applications where axial loading occurs primarily in one direction
- 40° Contact Angle: High contact angle design provides enhanced axial load capacity and improved rigidity, suitable for heavy-duty applications
- P5 Precision Grade: Superior tolerance and accuracy (ABEC 5) ensures smooth, consistent operation with minimal vibration and extended bearing life
- Bearing Pair Capability: Can be arranged in O- or X-configuration with low axial clearance for enhanced load distribution and improved performance in demanding applications
- Polyamide Cage: Lightweight and durable cage construction reduces friction and noise while ensuring reliable ball guidance
- Open Design: Allows for easy lubrication and maintenance in applications where regular servicing is feasible
Common Applications:
- High-precision spindles and machine tool applications
- Electric motors and precision pumps
- Gearboxes and power transmission systems
- Compressors and industrial machinery
- Automotive and precision engineering equipment
- Heavy-duty industrial equipment requiring combined radial and axial load capacity
- Applications operating in moderate temperature environments
The 7206-B-XL-TVP-P5-UA represents an excellent choice for high-precision industrial applications where superior accuracy, load capacity, and reliability are essential. Manufactured by FAG, a globally recognized bearing manufacturer renowned for quality and innovation, this bearing is ready for immediate dispatch.
