7204-BE-TVP NKE Single Row Angular Contact Ball Bearing 20mm x 47mm x 14mm
7204-BE-TVP NKE Single Row Angular Contact Ball Bearing
The 7204-BE-TVP is a precision single row angular contact ball bearing from NKE, engineered to handle combined radial and axial loads in high-speed applications. With a 20mm bore and 47mm outer diameter, this compact bearing delivers reliable performance across a wide range of industrial and mechanical applications requiring precision and durability.
Key Features:
- 40° contact angle for optimized load distribution and smooth operation
- Single row configuration ideal for applications with axial loads in one direction
- Polyamide cage design for lightweight operation and reduced friction
- Standard bearing steel construction with P0/PN2 (ABEC 1) tolerance class
- Normal radial clearance for flexible mounting applications
- Open bearing design without protective seals for applications where lubrication control is managed externally
- Open outer ring without flange or groove for straightforward installation
- Wide temperature operating range from -20°C to +120°C
Specifications:
- Bore Diameter: 20mm
- Outer Diameter: 47mm
- Width: 14mm
- Type: Single Row Angular Contact Ball Bearing
- Manufacturer: NKE
- Contact Angle: 40°
- Cage Material: Polyamide
- Seal Configuration: Open bearing (unsealed)
- Material: Standard bearing steel
- Clearance: Normal radial clearance
- Tolerance Class: P0/PN2 / ABEC 1
Applications:
This bearing is ideal for precision machinery, electric motors, spindles, gearboxes, pumps, and other equipment where combined radial and axial loads are required. The open design makes it particularly suitable for applications where bearing lubrication is carefully controlled or where integration with external sealing solutions is preferred. Its compact size and efficient design make it well-suited for:
- Electric motors and precision spindles
- Gearbox and transmission components
- Machine tool applications
- Industrial machinery and equipment
- High-speed precision applications
Reference Number: 7204-BE-TVP
