71812-TV INA Single Row Angular Contact Ball Bearing 60mm x 78mm x 10mm
Help Articles
Also Try
Tab Washers
Lock Nuts
Metric Oil Seals
Dunlop & Budget Ball Bearings
SKF Ball Bearings
Buy Now
Product Specification
Arrangement
Standard version
Brand
INA
Cage
Polyamide cage
Clearance
Normal radial clearance
Contact angle
Without indication, usually 30-40 degrees
Inside Dia
60mm
Material
Standard bearing steel
Outer ring
Without flange/groove
Outside Dia
78mm
Row Type
Single
Seal
None, open bearing
Temperature range
-30 to +120 °C
Tolerance class
Tolerance class P0/PN2 / ABEC 1
Width
10mm
Reference
71812-TV
Additional Reference:
10153206
Quick Order Code
BB-525448
Product Description
The 71812-TV INA Single Row Angular Contact Ball Bearing is a precision bearing engineered to handle simultaneous radial and axial loads in high-speed applications. This compact bearing combines INA's proven engineering with reliable performance, making it an excellent choice for space-constrained industrial assemblies.
Key Specifications:
- Bore Diameter: 60mm
- Outer Diameter: 78mm
- Width: 10mm
- Row Type: Single row configuration
- Contact Angle: 30-40 degrees for optimal load distribution
- Radial Clearance: Normal clearance
- Cage: Polyamide cage for lightweight durability
- Sealing: Open bearing design (unsealed)
- Material: Standard bearing steel construction
- Tolerance Class: P0/PN2 (ABEC 1)
- Operating Temperature Range: -30°C to +120°C
- Arrangement: Standard version
- Outer Ring: Without flange or groove
Applications:
This bearing is ideal for precision high-speed applications including:
- Electric motor assemblies
- Machine tool spindles
- Automotive components
- Industrial equipment requiring combined radial and axial load capacity in compact spaces
- Precision rotating machinery
Brand: INA | Reference: 71812-TV
