3211-BD-XL-2HRS-TVH FAG Double Row Angular Contact Ball Bearing 55mm x 100mm x 33.3mm
The 3211-BD-XL-2HRS-TVH FAG Double Row Angular Contact Ball Bearing is a robust precision bearing engineered for applications requiring simultaneous radial and axial load handling. This double-row configuration provides exceptional load capacity and stability, making it ideal for gearboxes, industrial machinery, automotive transmissions, and heavy-duty mechanical equipment.
Specifications:
- Reference: 3211-BD-XL-2HRS-TVH
- Brand: FAG
- Bore Diameter (Inside Diameter): 55mm
- Outer Diameter: 100mm
- Width: 33.3mm
- Row Type: Double row
- Contact Angle: 30 degrees
Key Features:
- Arrangement: Standard version for versatile load distribution
- Cage: Polyamide cage for reliable operation and reduced weight
- Material: Standard bearing steel for durability and long service life
- Radial Clearance: Normal clearance for standard applications
- Seal Type: Lip seal on both sides for enhanced protection against contamination and extended bearing life
- Outer Ring: Without flange or groove
- Tolerance Class: P6 / ABEC 3 for precision performance
- Operating Temperature Range: -20°C to +100°C
The 30-degree contact angle provides excellent support for combined radial and axial loads, while the double-row configuration ensures superior load capacity compared to single-row variants. The dual lip seals offer reliable protection in challenging operating environments, making this bearing well-suited for applications in gearboxes, spindle drives, industrial pumps, and other equipment requiring dependable, precision-engineered solutions.
